Features
  • Distributes 2 HDMI signals to up to 8 HDMI outputs
  • Supports 18Gbps for resolutions up to 4K UltraHD 60Hz
  • Supports HDMI 2.0a with HDCP, CEC, Auto Power ON/OFF, Auto-Switching
  • HDR format support, firmware updates via USB
  • Designed for 24/7 continuous operation, ideal for professional installations
SIMPLE 18Gbps SIGNAL DISTRIBUTION WITH JUST ONE DEVICE
The flexible switcher for HDR and 18Gbps!
The BV-HS2800H 2x8 HDMI HDR splitter included in the PureTools Series is a compact and portable design splitter with innovative sensor control panels and Smart Switch function for fast switching times. It allows for transmission of UltraHD / 4K / 2160p video signals and high quality audio signals from up to two different sources to a maximum of eight different playback devices without any loss of quality. It can be directly used as plug-and-play solution. Thanks to its USB port, it is quickly and simply updatable. An extendable CEC emulation function serves as individual EDID control between source and sink.
The PureTools Series - High Quality AV Products for Commercial Applications
Our practice-oriented PureTools Series distinguishes itself by perfected technology complying with the latest standards and smartest innovations. Due to this, the products included in the PureTools Series are exceptional talents which are crucial for professional installers.

Simple, Fast, Space-Saving
This PureTools splitter with integrated switcher allows for managing two HDMI input signals and eight HDMI outputs through a single device. A quick, flexible and especially simple use of input signals is guaranteed. The RS-232 input additionally provides a simple and quick control from one spot.

Uncompressed UltraHD Content and HDR Formats
With our PureTools HDMI HDR splitter, video and audio signals are being transmitted digitally and uncompressed in perfect quality. HDMI signals are being transmitted with a resolution of max. 4K / UltraHD / 2160p and up to 18Gbps bandwidth as well as unaltered digital audio signals up to 7.1 HD.

Integrated Signal Amplifier
The integrated signal amplifier allows for the use of the splitter within an overall system and between splitter and sink over greater distances. Crystal clear images and ultra-pure sound are being transmitted without loss of quality to any output.

Convincing - even in the Details
The splitters included in our PureTools Series are convincing in every detail, the devices profit from the optimisation for professional installations in known PureLink quality. With the transmission of RS-232 control signals as well as the integrated CEC emulation function, all precautions are taken for a professional use. The robust steel casing with optional installation into an AV rack simplifies the installation on location without any delays for installer and client.

For Professional Purposes and Installations
All PureTools splitters are manufactured in only the most modern production facilities and are tested a 100% before shipping. During the manufacturing process, the adapters undergo over ten quality tests, making them the most reliable choice on the market.
Features
Distributes 2 HDMI signals to up to 8 HDMI outputs
Supports 18Gbps for resolutions up to 4K UltraHD 60Hz
Supports HDMI 2.0a with HDCP, CEC, Auto Power ON/OFF, Auto-Switching
HDR format support, firmware updates via USB
Designed for 24/7 continuous operation, ideal for professional installations
Logistics Information
Product 1. Net Weight in Kg 0,94
Product 1. Gross Weight in Kg 0,94
Packaging 1. Weight in Kg 1
Product 1. Length in cm 21,5
Product 1. Width in cm 21,5
Product 1. Height in cm 6
Packaging 1. Length in cm 26
Packaging 1. Width in cm 23,5
Packaging 1. Height in cm 13
Master Carton Length in cm 55
Master Carton Width in cm 50
Master Carton Height in cm 31
Product Information
Europeans Customs Tariff Nr. 85176200000
Country of Origin Korea
Packaging Material Paper
VPE Information
Master Packaging Unit (pcs) 10
Secondary Packaging Unit (pcs) 2
Connections
Input connector(s) 2x HDMI, 1x RS-232, 1x IR, 1x USB
Output connector(s) 8x HDMI
Power connector(s) 12V3A DC
Control connector(s) RS-232, IR, USB
Electric signal
Digital video formats Max. 2160p@60Hz (YCbCr 4:4:4)
Digital audio formats HD Surround Sound (Dolby TrueHD, DTS HD) bis 7.1
HDCP Yes
CEC Yes
EDID Yes
Mechanical
Power supply Max. 10 Watt
Power consumption 12V3A DC
Operating temperature 0°C - 40°C
Storage temperature -20°C - 60°C
Humidity 20% - 90%
Enclosure PVC
Dimensions 223 x 195 x 63 mm
Signal transmission
Supported standards HDMI, HDMI Deep Color, RS-232, IR, USB
Weiteres
Safety WEEE, CE, FCC
Warranty 3 Years Manufacturer's Warranty
Delivery Content
1x BV-HS2800H
1x 12V3A Power Supply
1x IR Controller
1x User Manual
