PT-HDBT-1020C-RX – HDBaseT 3.0 USB-C Receiver: Uncompressed 4K Video and Data Extension for Integrated Displays
The PT-HDBT-1020C-RX utilises HDBaseT 3.0 technology to deliver uncompressed 4K (60Hz 4:4:4) video and USB 2.0 data over a single Cat.6a cable infrastructure. Designed for professional AV installations, this receiver features a dedicated HDBaseT input and a single USB-C output, supporting integrated video and HID-class peripherals on compatible displays. Its passive bi-directional power-over-cable (PoC) function streamlines deployment, while the robust metal housing and mounting provisions facilitate secure installation in meeting rooms, control rooms, and collaborative workspaces. Compatibility with PT-HDBT-1020 series and third-party HDBaseT 3.0 transmitters ensures flexible integration across diverse AV environments.

• 18Gbps 4K Video and HDCP 2.2: Supports uncompressed 4K video at 60Hz with 4:4:4 chroma subsampling, maintaining full image fidelity for high-resolution content. HDCP 2.2 compliance enables secure transmission of protected media, making it suitable for signage, conferencing, and presentation systems requiring content protection.

• HDBaseT 3.0 Transmission up to 100m: Employs HDBaseT 3.0 for full-bandwidth video and data transmission. Delivers 4K 60Hz 4:4:4 signals up to 80m, or 4K 60Hz 4:2:0 and 1080p up to 100m, supporting extended cable runs in large meeting spaces and control environments.

• USB-C Output for Integrated Displays: The USB-C port is engineered for screens with a single-port solution, combining video output and USB 2.0 / 1.1 HID data. This simplifies connectivity for touch displays or peripherals in collaborative and hybrid workspace installations.

• Bi-directional 24–48V Power over Cable: Features two-way PoC, allowing either the receiver or transmitter to supply power over the same Cat.6a cable. This reduces the need for local power supplies and streamlines installation in ceiling or wall-mounted setups.

• Professional Metal Housing with Mounting: The enclosure is constructed from metal for enhanced durability and electromagnetic shielding. Integrated mounting options support secure placement in racks, behind displays, or within lecterns in professional AV environments.

Reliable 4K Video and Data Extension for AV Installations
By combining HDBaseT 3.0 technology, uncompressed signal transmission, and integrated USB-C connectivity, the PT-HDBT-1020C-RX enables seamless extension of 4K video and data to displays and peripherals across up to 100 metres of Cat.6a cabling. This unit provides a technically robust solution for AV professionals seeking secure, long-distance signal distribution in meeting rooms, signage, and control room deployments.
