Features
  • Wireless 4-channel audio transmission, 2.4GHz, max. 15m line-of-sight
  • Integrated class-D amplifier (25W / 4Ω), volume control, on/off switch
  • Four channel clamp terminal input / output
  • Tx and Rx are pre-paired, re-pairing via push button on the front
  • 48KHz sample rate and frequency hopping for crystal clear audio
Wireless Speaker Set 15m
The CSW600 Wireless Audio Set enables wireless audio transmission over a maximum distance of 15m between transmitter and receiver. The four-channel / stereo system is ideal for 5.1 rear speakers, e. g. for home cinema, presentations and meetings. Transmission takes place in the 2.4GHz range, where many WiFi routers also work - both systems in one room at the same time can cause interference. The delivery includes transmitter and receiver as well as two speaker cables and two power supplies.
WIRELESS TRANSMISSION OF AUDIO SIGNALS
The name Cinema Series lives up to ist promises: Enjoy an HDTV cinema experience thanks to the latest specifications.

Wireless Audio in 15m
Wireless audio transmission in the 2.4GHz range, max. 15m distance (LOS) between transmitter and receiver, perfect for rear 5.1 speakers in homa cinemas.

Features:
- Direct wireless transmission of 2-speaker / 4-channel audio signals incl. class-D amplifier (25W / 4Ω), volume control and on/off switch
- The 48KHz sampling frequency as well as frequency hopping and WiFi auto-detection scheme provide crystal clear audio
- The Tx and Rx are pre-paired for an instantaneous use - Re-pairing possible via "ID Pairing" with push button on the front side
- The system includes one transmitter and one receiver module as well as two AC adapters and two speaker cables

Professional Quality
By purchasing a PureLink product, you always opt for first class professional quality. PureLink Wireless products master the challenge of transferring perfect quality even with high data rates.

Recommended Use
In home cinemas for the rear audio signal or for presentations, meetings and huddle spaces.
Features
Wireless 4-channel audio transmission, 2.4GHz, max. 15m line-of-sight
Integrated class-D amplifier (25W / 4Ω), volume control, on/off switch
Four channel clamp terminal input / output
Tx and Rx are pre-paired, re-pairing via push button on the front
48KHz sample rate and frequency hopping for crystal clear audio
Logistics Information
Product 1. Net Weight in Kg 0,21
Product 1. Gross Weight in Kg 0,23
Product 1. Length in cm 12,1
Product 1. Width in cm 8
Product 1. Height in cm 3
Packaging 1. Length in cm 24,5
Packaging 1. Width in cm 6,2
Packaging 1. Height in cm 16,6
Master Carton Length in cm 40
Master Carton Width in cm 30
Master Carton Height in cm 25
Product Information
Europeans Customs Tariff Nr. 85176200000
Country of Origin Taiwan
Packaging Material Plastic/Paper
VPE Information
Master Packaging Unit (pcs) 10
Connections
Input connector(s) Transmitter: 1x Stereo Speaker In (4-ch), 1x 5V Power | Receiver: Wireless In, 1x 18V Power
Output connector(s) Transmitter: Wireless Out | Receiver: 1x Stereo Speaker Out (4-ch)
Power connector(s) 5V / 18V DC
Electric signal
Digital audio formats 2-Channel, 48KHz/16bits Stereo
Mechanical
Power supply max. 2x 25W
Power consumption 18V / 5V DV
Operating temperature 0°C - 40°C
Enclosure Plastic
Dimensions 121x79.2x30.1 / 155x
Signal transmission
Supported standards Audio
Transmission modes Audio signals
Supported audio standards Stereo
Weiteres
Safety CE (EMC, RED, LVD, R
Colour black
Warranty 1 year
Delivery Content
1x CSW600 Transmitter
1x CSW600 Receiver
2x Speaker Cable
2x PSU
1x User Manual
