VBS-MAX-TX-1

Just Add Power 4K/60 4:4:4 Transmitter

Features
  • Supported Resolution - Computer and video resolution 4K60 @ 4:4:4 with deep colour up to 36-bit and support for HDR10, HDR10+, HLG, Dolby Vision, and SDR
  • Audio - Supports all lossless audio formats
  • Image Pull - Preview an image from any source or display in any web browser or control system - up to 10 fps
  • Integrated Endpoint Control – Control endpoints with RS232, IR and CEC
  • Scalability - Can run parallel and or be bridged with all 3G Ultra models (Bridging requires additional hardware)
Just Add Power 4K/60 4:4:4 Transmitter - Supports Dolby Vision™ and All HDR Formats
MAXCOLOR™
This new series natively supports 4K@60Hz in and out, allowing end users to play High Dynamic Range video, including Dolby Vision and HDR10+ formats, using the growing number of Ultra 4K sources and devices.
Use MaxColor™ 4K60 Transmitters and Receivers to create your new system, or bridge them to a 3G Ultra system to support a variety of source and screen formats.
4K60/4:4:4/36-bit video over a 1G network
The MaxColor™ 4K60 Transmitter natively supports 4K60 input, allowing you to distribute 4K UHD video from the growing number of 4K sources with no downscaling or subsampling. With MaxColor, 4K60/4:4:4/36-bit video can be distributed over a 1Gb managed network using existing Cat 5e/Cat 6 cable, eliminating the expense of upgrading to fiber and buying costly network switches. Use MaxColor 4K60 Transmitters and Receivers to create your new system, or bridge them to a system with 3G Ultra models to support a variety of source and screen formats.
Features
Supported Resolution - Computer and video resolution 4K60 @ 4:4:4 with deep colour up to 36-bit and support for HDR10, HDR10+, HLG, Dolby Vision, and SDR
Audio - Supports all lossless audio formats
Image Pull - Preview an image from any source or display in any web browser or control system - up to 10 fps
Integrated Endpoint Control – Control endpoints with RS232, IR and CEC
Scalability - Can run parallel and or be bridged with all 3G Ultra models (Bridging requires additional hardware)
Logistics Information
Product 1. Net Weight in Kg 0,47
Product 1. Gross Weight in Kg 0,47
Product 1. Length in cm 12,5
Product 1. Width in cm 12
Product 1. Height in cm 3
Packaging 1. Length in cm 24,5
Packaging 1. Width in cm 16,5
Packaging 1. Height in cm 5
Product Information
Europeans Customs Tariff Nr. 85176200000
Country of Origin USA
Packaging Material Plastic/Paper
VPE Information
Master Packaging Unit (pcs) 1
